Test Cell Measurement & Control

Measurement Systems for Test Cells Q.staxx

In the Q.staxx packaging configuration, Q.bloxx modules are housed in sealed enclosures, mounted onto a passive back plane that is attached to the skid. Depending on the measurements desired, the modules can be interchanged onto the back plane, and the sensors are directly connected to the modules prior to the skid entering the test cell. In this approach a completely functional measurement system is configured, wired, and verified prior to entering the system into the test cell. Once in the cell, only a single connection to the automation system is required. The Q.staxx line is based on the Q-series, therefore the technical data for the Q.bloxx modules applies.

  • Measuring and I/O modules for all common process signals
    Capture of electrical, thermal and mechanical values, I/Os for analog and digital signals
  • Compact robust design
    e.g. 4 universal channels (voltage, current, resistance, Pt100, TC, potentiometer, bridge) in one sturdy metal housing.
  • Synchronized, local signal capture
  • Sockets and attachment housing Protection Category IP65
    Protection category depending on connector selected
  • Flexibility in selection of I/O connectors
    TCK, BNC, 8 pin DIN, D-Sub and others
  • Modules can be plugged in at any point
    System expansion possible at any time
  • Modules can be cascaded on a number of channel sections
    from small units right up to comprehensive systems
  • Can be connected to test controller
    e.g. Q.station, Q.gate, or Q.pac
  • Electrical isolation
    between I/O signals, power supply and interface. Insulation voltage 500 VDC
  • Electromagnetic compatibility
    in compliance with EN 61000-4 and EN 55011
  • Power supply 10 to 30 VDC
  • Can be plugged into Han 16 A®Flange socket, 16 pin, Protection Category IP65,
    Channel section included as accessory



For more information about Q.staxx Test Cell DAQ, click here: Q.staxx

Author: Juergen Sutterlueti

Juergen Sutterlueti is Gantner Instrument's Vice President, Energy Segment and Marketing.
